CK6150

Category:

Flat Bed Hard Rail CNC Lathe

•Widened high stability bed
•The main shaft has three speed changes
•Variable frequency stepless in gear
•Widened carriage
•Automatic centralized lubrication

Tel：

+86-13371109792

Download：

Inquiry

Products

CNC Lathe Features

•Widened high stability bed
•The main shaft has three speed changes
•Variable frequency stepless in gear
•Widened carriage
•Automatic centralized lubrication

Specifications

Specifications	Unit	CYK6140	CYK6150	CYK6160
Max.swing over bed	mm	ф400	ф500	ф600
Max.swing over cross slide	mm	ф210	ф290	ф350
Width of bed	mm	360	400	440
Max.processing length	mm	600/850	850/1350/1850	850/1350/1850/2850
X axis travel	mm	X:210	X:250	X:330
Spindle transmission type	/	Independent spindle/internal frequency conversion	Independent spindle/internal frequency conversion	Independent spindle/internal frequency conversion
Spindle speed	rpm	32-1600/2000	20-1600/2000	20-1600/2000
Spindle nose	/	A2-6	A2-8	A2-8
Spindle bore	mm	Φ65	Φ82	ф82/105
Spindle motor	kW	5.5	7.5	11
X/Z Rapid traverse	m/min	6/8	6/8	6/8
X/Z axis repeatability	mm	±0.005	±0.005	±0.005
Processing accuracy	/	IT6-IT7	IT6-IT7	IT6-IT7
Workpiece surface roughness	/	Ra1.6	Ra1.6	Ra1.6
Tailstock sleeve dia.	mm	Φ65	Φ75	ф75
Quill traverse	mm	130	140	150
Quill taper	#	MT4	MT5	MT5
Tool post form	/	Electric 4-station/6 (8) station turret	Electric 4-station/6 (8) station turret	Electric 4-station/6 (8) station turret
Cutting tool shape size	mm	20x20	25×25	25x25/32x32
Machine dimension(LxWxH)	m	2.5×1.42×1.66	2.8×1.7×1.8	3.1x1.8x1.85
Net.weighe(about)	T	1.7/1.9	2.6/3.2	3.1/3.6/4.0/4.5
